Product Details:
Payment & Shipping Terms:
|
| Color: | Blue / Red / Green / Gery / White | Length: | Customzied |
|---|---|---|---|
| Width: | 1130mm/930mm/920mm | Type: | S Tile |
| Thickness: | 1.0mm/1.3mm/1.5mm/1.8mm/2.0mm | Material: | Pvc Resin |
| Surface: | Smooth Surface | ||
| High Light: | plastic spanish roof tiles,corrugated pvc roofing sheets |
||
UPVC Material PVC Plastics Construction Material Color Sheet Parking Roof Tiles Philippines
Our skilled technical team and high-standard quality control, we are able to product high quality products and manged to keep our cost performance at a high level.
| Product name | PVC Corrugated Roof Sheet | |||||
| Length | 5800mm , 11800mm or customized | |||||
| Type | corruagted type , Trapezoidal type | |||||
| Overall width | 1130mm | |||||
| Effective width | 1000mm(round wave type) , 1050mm(trapezoidal type) | |||||
| Purlin spacing | 700~900mm | |||||
| Colors | Blue,white,green,grey or customized | |||||
| Surface | Smooth surface | |||||
| Thickness | 1.3±0.1mm | 1.5±0.1mm | 1.8±0.1mm | 2.0±0.1mm | 2.5±0.1mm | |
| Weight | 2.49±1kg/m2 | 2.88±0.1kg/m2 | 3.45±0.1kg/m2 | 3.84±0.1kg/m2 | 4.8±0.1kg/m2 | |
Advantages:
1. Refractory
Strong fire-retardant;according to the test, fireretardant≥B1 level
2. Insulations
The products is insulation material that will be safe when the accidental discharges happened
3. Noise insulation
Good noise absorbing funtion,it has sound insulation effect, can effectively filter the sound of 35% - 50%
Application:
| warehouses | balcony | hight-grade plants |
| sheds | farm markets | farm market |
| Factories | road hoarding | soy sauce factory |
Container Load:
| Thickness | SQ.M./20 FCL (21 Tons) | SQ.M./20 FCL (26 Tons) |
| 1.0mm | 11000 m2 | 13600 m2 |
| 1.5mm | 7200 m2 | 9000 m2 |
| 1.8mm | 6100 m2 | 7600 m2 |
| 2.0mm | 5500 m2 | 6800 m2 |
| 2.5mm | 4300 m2 | 5400 m2 |
| 3.0mm | 3600 m2 | 4500 m2 |
